| Pixel Pitch | 3.91mm | 4.81mm | 5.95mm | 6.25mm |
|---|---|---|---|---|
| Physical Density | 65746/m2 | 43264/m2 | 28224/m2 | 25600/m2 |
| LED Shape | SMD1921 | SMD2727 | SMD3535 | SMD3535 |
| LED Configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Drive Mode | 1/16 Scan | 1/13 Scan | 1/7 Scan | 1/10 Scan |
| Cabinet Size | 500x500mm | 500x500mm | 500x500mm | 500x500mm |
| Cabinet Resolution | 128x128 | 104x104 | 84x84 | 80x80 |
| Cabinet Weight | 8kg/pc | 8kg/pc | 8kg/pc | 8kg/pc |
| Brightness | ≥5000cd/m2 | ≥5000cd/m2 | ≥5500cd/m2 | ≥4300cd/m2 |
| Contrast | ≥2000:1 | ≥2000:1 | ≥2000:1 | ≥2000:1 |
| Viewing angle(H/V) | 140°/140° | 140°/140° | 140°/140° | 140°/140° |
| View Distance | ≥4m | ≥5m | ≥6m | ≥6m |
| Gray Scale | 16bits | 16bits | 16bits | 16bits |
| Color Capacity | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Maximum Power | 300 W/PC | 200 W/PC | 250 W/PC | 200 W/PC |
| Average Power | 100 W/PC | 70 W/PC | 80 W/PC | 70 W/PC |
| Input voltage | 110 / 220V | 110 / 220V | 110 / 220V | 110 / 220V |
| Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
| Working Temperature | -20℃～+50℃ | -20℃～+50℃ | -20℃～+50℃ | -20℃～+50℃ |
| Operating Humidity | 10-90% RH | 10-90% RH | 10-90% RH | 10-90% RH |
| Life Span | 100,000Hours | 100,000Hours | 100,000Hours | 100,000Hours |
| IP rating(Front/Rear) | IP65/IP54 | IP65/IP54 | IP65/IP54 | IP65/IP54 |
