| Pixel Pitch | 6.66mm | 10mm |
| Physical Density | 22500/m2 | 10000/m2 |
| LED Shape | SMD3528 | SMD3528 |
| LED Configuration | 1R1G1B | 1R1G1B |
| Module Size | 320x160mm | 320x160mm |
| Module Resolution | 48x24 | 32x16 |
| Drive Mode | 1/12 Scan | 1/8 Scan |
| Cabinet Size | 960x800mm | 960x800mm |
| Cabinet Resolution | 144x120 | 96x80 |
| Cabinet Weight | 60±1kg/m2 | 60±1kg/m2 |
| Brightness | ≥1200cd/m2 | ≥1000cd/m2 |
| Contrast | ≥2000:1 | ≥2000:1 |
| Viewing angle(H/V) | 140°/140° | 140°/140° |
| View Distance | ≥6m | ≥10m |
| Gray Scale | 16bits | 16bits |
| Color Capacity | 281 trillion | 281 trillion |
| Maximum Power | 450 W/m2 | 300 W/m2 |
| Average Power | 150 W/m2 | 100 W/m2 |
| Input voltage | 110 / 220V | 110 / 220V |
| Refresh Rate | ≥1920Hz | ≥1920Hz |
| Working Temperature | -20℃～+50℃ | -20℃～+50℃ |
| Operating Humidity | 10-90% RH | 10-90% RH |
| IP rating(Front/Rear) | IP40/IP21 | IP40/IP21 |
| Life Span | 100,000Hours | 100,000Hours |
